Larsen’s Architectural Series – Model SSC2409-R
(MP10)
Recessed Stainless Steel Cameo Bubble Style Fire Extinguisher Cabinet
The Cameo cabinet has a bubble design that protects the
fire extinguisher while providing full 180° visibility. The extinguisher remains
visible and accessible.
Features:
- Designed for installation in shallow wall spaces without sacrificing
accessibility.
- The projecting bubble protects the extinguisher while providing a clear,
unobstructed view from virtually any angle.
- A rear mounting bracket is included with each fire extinguisher cabinet
to support the unit inside the cabinet.
- Standard door and trim are made from durable steel, with optional
finishes available in aluminum, stainless steel, acid bronze, and brass.
- The door frame features a 12-inch kick below-recessed construction for
lasting strength.
- A satin-finish pull handle with an adjustable cam lock and continuous
piano hinge provides operation of the cabinet.
- The cabinet includes concealed hinges.
- Available with all door styles for added security and simple
installation.
Lock SpecificationThe Larsen-Lock
locking system provides quick access to locked fire extinguisher cabinets
without the need to break glass in an emergency. The door opens by pulling
firmly on the handle.
Each unit includes a factory-applied decal reading “IN
CASE OF FIRE ONLY - PULL FIRMLY ON HANDLE.”
Door SpecificationAll recessed and
semi-recessed wall cabinets and surface-mounted wall cabinets have a heavy
gauge, white baked-enamel box. Surface-mounted cabinets with aluminum door and
trim have a box constructed entirely of aluminum or color anodized aluminum.
Surface-mounted cabinets with stainless steel door and trim have a box
constructed entirely of 304 stainless steel with a #4 finish.
Trim and Door SpecificationStainless
steel trim and door are one piece, constructed of heavy gauge #18 304 stainless
steel.
Polished stainless steel finishes are available as an
option.
Also available in steel and aluminum.
